VA05-Mag 4G Magnetic GPS Tracker | 5000mAh Rechargeable & Light Anti-Dismantle

The Best Balanced Magnetic Tracker. VA05-Mag is a versatile 4G tracker with a 5000mAh rechargeable battery. Rechargeable: 5000mAh battery for repeated use. Anti-Theft: Light Sensor Alarm + Strong Magnets. Versatile: Perfect for car rental and personal assets.

Parameters & Specifications

More detailed information

5000mAh Rechargeable Battery: Offers excellent standby time (weeks to months depending on settings) without the bulk of larger units.

Cost-Effective: Ideal for Car Rental Fleets and Personal Anti-Theft. Use it, recover it, recharge it, and deploy it again.

Light Sensor Anti-Dismantle: A light sensor is embedded on the magnetic back. If the device is removed from the car chassis, the sudden exposure to light triggers an Instant Alarm to your phone.

Strong Magnetic Mount: Six industrial-strength NdFeB magnets ensure it stays attached to vehicles even on bumpy roads. No installation costs.

Real-Time Tracking: Switch to this mode to recover a stolen vehicle (updates every 10s-30s).

Power Saving Mode: Uploads once a day to maximize battery life for long-term monitoring.

Blind Zone Memory: Stores location data when the 4G signal is lost (e.g., underground garages) and uploads it later.

✅ Perfect For	❌ NOT Recommended For
Car Rental/Loans: Reusable asset protection.	5-Year Standby: Needs recharging periodically. For 5-year battery, use VA09-Dry.
Private Car Anti-Theft: Strong magnet hides under seats.	Cold Chain: No temperature sensor. Use VA08-Temp for reefer trucks.
General Assets: Good balance of size/power.	Mini Size: VA03-Dry is slightly smaller if size is the #1 priority.

Battery: 3.7V 5000mAh Li-Polymer (Rechargeable).
Dimensions: 78mm × 54mm × 21mm.
Weight: 132g.
Network: 4G LTE Cat-1 + 2G Fallback.
Positioning: GPS + BDS + AGPS + LBS.
Waterproof: IP65 (Splash proof).

Technical Parameter	Specification Details
Model Name	VA05-Mag
Battery Capacity	5,000mAh (Rechargeable Li-Polymer)
Voltage	3.7V - 4.2V
Mounting	Strong Magnetic (6x NdFeB)
Anti-Theft	Light Sensor (Anti-Dismantle)
Network	4G LTE (SIMCOM 7670C)
Dimensions	78mm × 54mm × 21mm
Weight	132g
Positioning	GPS + BDS + LBS
Waterproof	IP65

1. Charging Instructions

Rechargeable: This device has a charging port. Please use a standard 5V USB charger.
Cable: Use the provided magnetic or USB cable (check box content).
Status: Fully charge the device before first deployment.

2. Anti-Dismantle Setup

Light Sensor: Located on the back.
Installation: Must be attached firmly to a surface to cover the sensor (keep it dark).
Alarm: If removed -> Light Detected -> Alarm sent.

3. SIM Card Install
